Fish Meal Machine Production Line with Factory Price

Packaging Type: Case Packaging Material: Wood Automatic Grade: Automatic Driven Type: Electric

Description

Packaging & Delivery

Packaging Details	Fishmeal Production Line packaged with film
Delivery Time	Fishmeal Production Line within 30 days after deposit

Product Description

1. Model : SSS-YE-30

2. capacity of raw material：300kg/hour

3. capacity of fish meal: 70-80kg/hour

4. moisture of final product: less than 12%

5.final product: skimmed fish meal

Item	description	dimension	details
1	Screw conveyor	φ160×4000	equipped with reducer 1 set, made of SUS304
2	electrical cooker	φ325×3500	·material of outer heat preservation made of SUS43O, thickness: 0.7mm; ·inner and outer cylinder made of Q235B; ·driving power: 1.5kw (speed adjusted by magnetization).
3	screw press	φ219×1200	·outer cover made of SUS304, thickness 1.2mm; · seive mesh applied SUS304; .driving power: 1.5kw.
4	electrical heating dryer	φ800×3500	·inner and outer cylinder made of Q235B; ·preservation made of SUS43O, thickness 0.7mm; ·driving power: 4kw, V=30r/min;
5	heat contacting oil pump		driving power:1.5kw
6	electric control box		electric control box 1 set
