Features:

1.High strength intergrated platform including sliding plate,front size can be adjusted recesses for wheel alignment.

2.Platform is from the ground 200mm slim design for low-chassis vehicles.

3.Internal platform plus welding reinforcing ribs(with bilateral support board for the long body of the vehicle),highstrength/resistance to deformation.

4.High intensity beam beams,giving stable support the body when fully loaded.

5.Manual safety lock structure,synchronization lock or unlock the security lock,lock a file every 80mm foot holes,safe and reliable.

6.Balance rope using double anti-fracture design,using high-strength alloy steel core wire harness stranded,and pre-tensioning process.

7.Built-in anti-shedding dog rope/wire rope anti-breaking device,improving safety and performance.

Dribe mode:

Hydraulic rope traction

Hydraulic system:

Cylinder use of new technology scraping roller cylinder/seal combined,double support-oriented,with a long stroke in stable to withstand high load characteristics.
High-quality pump stations,to provide a stable hydraulic supply(with overload protection),wigth emergency power decline knob.

Electrical System:

Through the control cabinet panel to control the rise/total power
Setting a maximum lift position limit switch protection,to protect the fuel tank from impact.
An optional electronically controlled pneumatic unlocked.
