NO.

Description

Parameter

1

X,Y,Z Working Area

600x900x100mm

2

Table Size

890X1200mm

3

X,Y,Z Traveling Positioning Accuracy

±0.03/300mm

4

X,Y,Z repositioning Positioning Accuracy

±0.02mm

5

Table Surface

T-slot Extrusions

6

Frame

Cast Steel

7

X, Z Structure

Ball Screw

8

Y Structure

Hiwin Rail Linear Bearings and Ball Screw

9

Max. power Consumption

0.8Kw

10

Max. Rapid Travel Rate

6000mm/min

11

Max. Working Speed

4000mm/min

12

Spindle Power Motor

1.5Kw self cooling spindle

13

Spindle Speed

0-24000RPM

14

Drive Motors

Stepper system

15

Working Voltage

AC220V/50/60Hz

16

Command Language

G code

17

Operating System

NC-Studio

18

Interface

USB

19

Flash Memory

128M(U Disk)

20

Collet

ER16

21

X,Y Resolution

<0.01mm

22

Software Compatibility

Type3 software, Ucancam software, (Option: Artcam software)

23

Running Environment

Temperature: 0°C~45°C
Relative humidity: 30%~75%

24

Packing Size

1710 x 1250 x 1585mm

25

Net Weight

180KG

26

Gross Weight

272KG
