Scissor Lift

Model Number: QJ/Y-J-35Please contact us:yx@mec.com.cn

Parameter

Model : LG30

Input capacity/batch : 400~500kg

Description

Features:

1.Plates containing the sliding plate,front size can be adjusted recesses for wheel alignment(including the new 3D technology locator)

2.Built-secondary lifting platform,vehicle lift for wheel alignment adjustment

3.High strength rectangular tubular support arm plus welding reinforcing rib structure(16Mn(Q345 manganese)to give the body full load Scissor stable support any operating angle.

4.Internal platform plus welding reinforcing rib plate,high strength/resistance to deformation

5.Built-lubricatging bushing rotating shaft member

6.Using pneumatic safety lock structure(with synchronous unlocking safety device)

7.Enhanced self-lubricating nylon sliders.

Hydraulic system:

Amodular sealing fuel tanks
High-quality pump stations,to provide a stable hydraulic supply(with overload protection)

Drive mode:

Hydraulic double cylinder(tandem master cylinder deputy)

Electrical System:

Through the control cabinet panel to control the rise/fall/pneumatic unlocking.
Setting a maximum lift position limit switch protection,to protect the fuel tank from impact
Optional unbalanced bilateral deck photoelectric control accessories.

Details:

Model:	QJ/Y-J-35
Lifting capacity:	3500kg
Mini height:	360mm
lifting length:	1950mm
second lifting height	450mm
platform width:	610mm
platform length:	4000/4300/4500mm
