Hydraulic four post lift
Model number:HY-PBS-C-6340
please contact us:
yx@mec.com.cn
Description
- l Adopt the electric release, manual and pneumatic release.
- l Hydraulic power unit configuration throttling device, they can always adjust the rate of decline.
- l Hydraulic cylinder drive, rope drive, quiet and smooth lifting.
- l With wire control security lock, with a wire rope fracture protection, operation safety.
- l Adopt electrical release, eight-point locking system, easy to operate.
- l Can be locked in the desired height of operation, safety and reliability
- l Runway spacing is adjustable for different wheel base vehicle.
- l With the second lift pulley.
Technical specifications:
| Lifting Capacity |
3500kg 4000kg 5000kg |
| Platform Lifting Height |
1500mm |
| Secondary Lifting Height |
350mm
|
| Min.Height |
200mm
|
| Motor Power |
3500kg-2.2kw/5000kg-3.0kw |
| Power Supply |
220v-380v |
| Rated Oil Pressure |
18Mpa |
| Weight |
1200kg/1560kg |
| Outline Dimensions |
L4200*W550*H200mm |
