Manufacturer Light Steel Rail

produced by continuous billets, products quality is stable in chemical composition and mechanical properties;good price can be got from our mill and cooperative mills.

Product Details Company Profile

Description

Model NO.: GB 11264-89

Certification: ISO9001

Rail Heigth: 63.50mm-107.95mm

Web Thickness: 5.90mm-12.30mm

Trademark: Honory

Specification: 9kg/m, 12kg/m, 15kg/m, 22kg/m, 24kg/m, 30kg/m

HS Code: 73021000

Customized: Customized

Type: Light Rail

Bottom Width: 63.50mm-107.95mm

Head Width: 32.10mm-60.33mm

Transport Package: in Bundles

Origin: China

	Height (mm)	Bottom	Head	Web	Theoritical	Length
		Width (mm)	Width (mm)	Thickness (mm)	weight	(m)
					(kg/m)
9kg	63.50	63.50	32.10	5.90	8.94	5-7
12kg	69.85	69.85	38.10	7.54	12.20	6-10
15kg	79.37	79.37	42.86	8.33	15.20	6-10
22kg	93.66	93.66	50.80	10.72	22.30	7-10
24kg	107	92	51	10.90	24.46	6-10
30kg	107.95	107.95	60.33	12.30	30.10	7-10
