S9 Series 11kv 630 KVA Oil Immersed High Voltage current transformer

The product has been widely used in places with high fireproof&explosionproof requirements, such as power transmission and transformation system, commercial street, sport stadium, petrochemical enterprise, metro, railway station, airport and etc.

Product Details Company Profile

Description

Place of Origin: Hunan, China (Mainland)
Brand Name: Varelen
Model Number: S11
Usage: Power
Phase: Three
Coil Structure: Toroidal
Coil Number: 2
Type: Oil Immersed
Certification: ISO9001:2008
Color: Grey or Optional
Rated voltage: 10kV 11kV 20kV 33kV 35kV
Standard: IEC60076
Frequency: 50Hz/60Hz

1. Product Discription

Benefits:

1. Ultralow no-load loss, reduce about 80% of no-load loss of S9 series;

2. Energy saving and great power consuming efficiency;

3. Copper foil winding, strong short circuit resistance ability;

4. Dyn11 coil connection would bring down the influences of harmonic wave on electric network and increase the efficiency of power grid;

5. Fully sealed structure, maintenance free;

6. Environment-friendly amorphous core, less manufacturing electricity comsumption and pollution gas;

7. Low running temperature, slow insulation aging, longer serving life, great reliability;

8. Vacuum oil filling , high stability of insulation.

Application:

The product has been widely used in places with high fireproof&explosionproof requirements, such as power transmission and transformation system, commercial street, sport stadium, petrochemical enterprise, metro, railway station, airport and etc.

2. Technical Parameter
