Single Scissor Lift

Model Number:HY-LZD-A-1527 please contact us: yx@mec.com.cn

Description

The hydraulic parking lift use the platform to support the car, the platform adopted by the supportive of length and width, have the characteristic of compact structure, less space, light weight, move convenient, running stable, good quality pump and electronic units, mechanical racks self-lock and hydraulic pressure are adopted, safe and credible, no need the preparation of the basement, could install on the ground directly.

Technical specifications:

Lifting Capacity                 2700kg
Lifting Height 1800mm
Lifting time 55-60s
Min.Height 140mm
Overall Height 2550mm
Motor Power 3.0kw
Power Supply 220v/240v/380v/415v
Rated Oil Pressure 18Mpa
Noise 70dB
Outline Dimensions L1968*W1226*H2550MM
Weight 850KG
