XJ1325 Styrofoam cnc router

Styrofoam CNC Router can work on wood, EPS and non-metallic carbon material, making automotive foam mold, wooden metal aviation, trains and other wooden mold,carving 3D musical instruments,bumper,bonnet interior trim mold and aviation etc.

Product Details Company Profile

Description

Feature and specialties:
(1)Adopt Shanghai Ncstudio control system,high precision,fast speed,German transmission system,Italy imported spindle
(2)Imported four-rpw ball bearing,linear guide widening,self-lubricating block to make equal force in all directions to ensure the mechanical accuracy and strength
(3)Z axis can be up to 1m,can work for material which are big and thick
(4)Intelligent processing cross-border protection,to prevent the mechianical impact due to excessive design document processing.

Applications:
Styrofoam CNC Router can work on wood, EPS and non-metallic carbon material, making automotive foam mold, wooden metal aviation, trains and other wooden mold,carving 3D musical instruments,bumper,bonnet interior trim mold and aviation etc.

Options:
Diving system:Panasonic/Yaskawa/Delta servo system
spindle: HSD, Colombo, Chinese GS/GDZ/HQD spindle

inverter: SIFANG inverter,Fuling inverter

No.	Description	XJ1325
1	XYZ working size	13002500600mm
2	Working table	PVC and T-slot
3	Gantry	Steel gantry
4	Lathe structure	Welding steel tube frame with cement filling
5	Transmission system	Rack pinion for X/Y, Ball screw for Z
6	Driving system	Leadshine860
7	Repositioning accuracy	±0.03mm
8	Max. travelling speed	50000mm/min
9	Max. working speed	30000mm/min
10	Spindle and collet	5.5kw water-cooling spindle
11	Spindle speed	24000rpm
12	Working voltage	380/3ph
13	Command code	G code(uoo, nc, mmg, plt)
