ZFJ Series Chinese Herbal Medicine Pulverizer

The machine is applied in industries such as pharmaceutics, foodstuff, chemicals and etc, with features of cool air and no sieve or screen. It is not limited by the viscosity, hardness ,softness or fiber shape of the raw materials, and has good effect to all materials, especially to those Chinese herbal medicines with fibers and those with oils.

Product Details Company Profile

Description

The machine is applied in industries such as pharmaceutics, foodstuff, chemicals and etc, with features of cool air and no sieve or screen. It is not limited by the viscosity, hardness ,softness or fiber shape of the raw materials, and has good effect to all materials, especially to those Chinese herbal medicines with fibers and those with oils.

二Working Method

The machine is composed of feeder,grading wheel,pulverizing blades,gears,pulverizing motor,discharging gate,fans,collection box,dust collection box and etc.Any raw material,being feed into the grind chamber through the upper feeder,is pulverized by high-speed running blades.The fineness of the finished products is regulated via the distance adjustment of grading wheel and grading plate.The high-speed running fans will lead those pulverized material from grinding chamber to discharge gate via negative pressure while whose unpulverized remained in the chamber.The dust from grinding is filtered and recycled via the cloth bag or filter of the dust absorption box.The whole machine,designed according to GMP standard,is made of stainless steel,with the features of easy structure,convenient operation and cleaning,low noise and high capacity,avoiding dust flying in production.

三 Technical Data

Model	200	300	400
Capacity(kg/h)	10-150	20-300	50-500
Size of input granules(mm)	≤10	≤12	≤15
Fineness of products(Mesh)	20-250
Grinding power(kw)	5.5	7.5	11
Dust absorption power(kw)	1.5	2.2	3
Weight(kg)	320	550	750
Overall Size（L×W×H）mm	1350×920×800	1400×1050×2050	1600×1150×210
