1) 135-143 Celsius UHT sterilization for aseptic liquid products
2) exchanger corrugated tubes in tube.
3) full automatic
UHT sterilizer is Ultra High Temperature sterilization for aseptic liquid products. The type is tubes in tube.
Type--- corrugated tubular heat exchanger for indirectly heating product.
Operation function---The operation have 4 steps: Disinfection, Sterilization, Producing, CIP cleaning. They are controlled by PLC automatic in order to ensure the of the process.
The parts include---Aseptic valve, steam reduce valve, steam adjusting valve, control valve, pump, shelf etc..
Complete aseptic security--- complicated process flowchart to ensure the aseptic of the product.
Low consumption of energy--- per 5 000L/h product ≤320kg/h steam
Connect with other equipments---- Aseptic Storage Tank, Aseptic Packing Machine directly, homogenizer, vacuum deaerator.
Parameter:
|
Capacity
L/h
|
Power
kw
|
Steam (during production)
kg/h
|
|
1 000
|
9.0
|
25.0
|
|
2 000
|
9.0
|
40.0
|
|
3 000
|
11.0
|
60.0
|
|
5 000
|
15.0
|
90.0
|
|
10 000
|
20.5
|
185.0
|
|
15 000
|
26.0
|
290.0
|
|
20 000
|
33.5
|
380.0
|
