FEM1 3phase 63A Manual Type Moulded Case Circuit Breaker MCCB

FEM1 series moulded case circuit breaker is a new type product developed and manufactured by Adopting international advanced technology.

Product Details Company Profile

Description

Model NO.: FEM1
Operation: Manual Type
Arc-extinguishing Medium: Air
Structure: MCCB
Type: Circuit Breaker
Certification: CE, CCC
Current: 125A,250A,400A,630A,800A,1250A
Pole: 2p,3p,4p
Characteristic Curve: C
Electrical Life: More Than 8000times
Installation Altitude: ≤2000m
Transport Package: Standard Export Box Package
Origin: Zhejiang China

Breaking Capacity: Low Voltage Circuit Breakers
Speed: Normal Type Circuit Breaker
Installation: Fixed
Poles Number: 3
Function: Conventional Circuit Breaker, Circuit-Breaker Failure Protection, Overcurrent Protection, OVP(Overvoltage Protection)
Break Capacity: 50ka
Volatage: 690V/800V
Standard: IEC/En60947
Protection Degree: IP20
Mechanical Life: More Than 2000times
Trademark: FEEO
Specification: CE&TUV&RoHS&ISO9001 certificat
HS Code: 8536200000

MCCB Application:
FEM1 series moulded case circuit breaker is a new type product developed and manufactured by Adopting international advanced technology. It is supplied with rated insulation voltage 800V and used for circuit of AC 50Hz, rated operation voltage AC 400V or below rated operation current up to 1600A for infrequent changing over and starting of the motors. Equipped with the protection devices for over-current, short circuit and under voltage, the product is capable of preventing damage of circuits and supply units. The product conforms to IEC60947-2 standard.

MCCB Parameters:

Item	AC MCCB
Code	FEM1-125	FEM1-250	FEM1-400	FEM1-630	FEM1-800	FEM1-1250
Pole	2P,3P,4P	2P,3P,4P	3P,4P	3P,4P	3P,4P	3P,4P
Voltage	690v/800v
Current	6A,10A,16A, 20A,25A,32A, 40A,50A,63A, 80A,100A,125A	100A,125A, 140A,160A 200A,225A, 250A	250A 400A	400A 500A 630A	630A 700A 800A	800A, 1000A, 1250A
Standard	IEC/EN60947
Breaking Capacity	35KA	35KA	50KA	50KA	75KA	75KA
Characteristic Curve	C
Working Temperature	"-5°"to +40°
Protection Degree	IP20
Electrical life	More than 8000times
Mechanical life	More than 2000times
Installation	35MM DIN RAIL
Accessory	YES
Installation Altitude	≤2000M
