Technical Parameters Of 27-10

Output:10000~13000 piece/hour(50g)(max)(Feed-in temperature below 5℃)       Weight/piece:50~250g

Mould:

a.number of moulds in each row:10piece                 b.mould line:140 piece

Electrical:

a.phase:3Phase                             b.voltage:380v

c.frequency:50Hz                           d.power of mould-stripping pump:0.75kw

e.power of milk pump:0.75kw       f.power of vacuum pump:2.2kw

g.Main power:ab10kw                   h.inner circle pump:5.5kw

Air:

a.pressure:0.6Mpa    b.consumption air:3m³/min

Steam:

a.pressure:0.05≤P≤0.25Mpa      b.temperature:＜120℃     c.consumption:ab60kg/hour

Secondary Refrigerant:

a.density:32Baume degrees                    b.flowing:150m³/hour

c.temperature:<-30℃                             d.PH:8~9PH

Cooling volume(working conditions±35℃):ab130kw

Stick Specification:(93~140)x10x2mm

Dimention(LxWxH):4920x3125x2100mm

Weight:8T

Pipe connection:

a.compressed air:1/2 inch           b.steam:1/2 inch      c.inlet of brine:Φ114

Technical Parameters Of 30-12

Output:15000 piece/hour(50g)(max)(Feed-in temperature below 5℃)       Weight/piece:50~250g

Mould:

a.number of moulds in each row:12piece                 b.mould line:140 piece

Electrical:

a.phase:3Phase                             b.voltage:380v

c.frequency:50Hz                           d.power of mould-stripping pump:0.75kw

e.power of milk pump:0.75kw       f.power of vacuum pump:2.2kw

g.Main power:ab10kw                   h.inner circle pump:5.5kw

Air:

a.pressure:0.6Mpa    b.consumption air:3m³/min

Steam:

a.pressure:0.05≤P≤0.25Mpa      b.temperature:＜120℃     c.consumption:ab60kg/hour

Secondary Refrigerant:

a.density:32Baume degrees                    b.flowing:150m³/hour

c.temperature:<-32℃                             d.PH:8~9PH

Cooling volume(working conditions±35℃):ab165kw

Stick Specification:(93~140)x10x2mm

Dimention(LxWxH):4920x3128x2100mm

Weight:8.6T

Pipe connection:

a.compressed air:1/2 inch           b.steam:1/2 inch      c.inlet of brine:Φ114

Technical Parameters Of 35-16

Output:15000~17000 piece/hour(50g)(max)(Feed-in temperature below 5℃)       Weight/piece:50~250g

Mould:

a.number of moulds in each row:16piece                 b.mould line:140 piece

Electrical:

a.phase:3Phase                             b.voltage:380v

c.frequency:50Hz                           d.power of mould-stripping pump:0.75kw

e.power of milk pump:0.75kw       f.power of vacuum pump:2.2kw

g.Main power:ab10kw                   h.inner circle pump:5.5kw

Air:

a.pressure:0.6Mpa    b.consumption air:3m³/min

Steam:

a.pressure:0.05≤P≤0.25Mpa      b.temperature:＜120℃     c.consumption:ab60kg/hour

Secondary Refrigerant:

a.density:32Baume degrees                    b.flowing:180m³/hour

c.temperature:<-30℃                             d.PH:8~9PH

Cooling volume(working conditions±35℃):＞180kw

Stick Specification:(93~140)x10x2mm

Dimention(LxWxH):5370x3550x2100mm

Weight:12T

Pipe connection:

a.compressed air:1/2 inch           b.steam:1/2 inch      c.inlet of brine:Φ144
