Place of Origin: Guangdong, China (Mainland)

Material: Stainless Steel Wire, Stainless Steel Wire, 302,304,316,316L,8020

Type: Weave Wire Mesh

Application: Woven Wire Mesh, Mine Sieving Mesh,and Basket,etc

Weave Style: Plain Weave, Plain Weave

Wire Diameter: 0.018mm

Technique: Woven

Model Number: 1-1000 mesh

Brand Name: Boda

Product name: Welded wire mesh

Hole: 0.0455mm

Mesh size: 1-500

Width: 0.3M-5M

Length: 15M-100M

Diameter: 0.018mm-2mm

Feature: Anti-acid, Resistant to rust

Delivery Time: In 20-30 days

Packaging & Delivery

Product Description

Our stainless steel wire mesh products are generally made of stainless steel Type

302,304,304L,316,316L,321 and 430 etc. We produce wire cloth in all kinds of forms. The weaving is

determined by our customers’ specific requirements, such as the material, the wire diameter, the size of

the mesh , width and length.

Weave type explanation

1. Plain Weave: also called tabby weave, linen weav or taffeta weave, is the most basic type of weaves.

In plain weave, the warp and weft are aligned so they form a simple criss-cross pattern. Each weft thread

crosses the warp threads by going over one, then under the next, and so on. The next weft thread goes

under the warp threads that its neighbor went over, and vice versa.

2. Twill Weave: In a twill weave, each weft or filling yarn floats across the warp yarns in a progression of

interlaces to the right or left, forming a distinct diagonal line. This diagonal line is also known as a wale. A

float is the portion of a yarn that crosses over two or more yarns from the opposite direction.

3. Plain Dutch Weave: similar with plain weave, just the weft and warp wire have different wire diameter

and different mesh size.

4. Twill Dutch Weave: similar with twill weave, just the weft and warp wire have different wire diameter and

different mesh size.

5. Reversed Dutch Weave: difference from standard Dutch weave lies in the thicker warp wires and less

weft wires

Features of Stainless Steel Sieving Wire Mesh

High tension: Much higher tension than common polyester mesh and smooth tension;

Super precision: Uniform wire diameter and aperture with extremely low difference;

Low elongation: Very small elongation of wire mesh at high tension;

High flexibility: The wire mesh will not lose elasticity at extreme tension;

High corrosion resistance: The excellent corrosion resistance of stainless steel wire exceeds polyester

fiber;

Non-electrostatic: To avoid affects of non-electrostatic for print and ensure the safety of printing;

Good heat-melting resistance: Special features of stainless wire mesh. Suitable for heat-melting ink;

Good solvent resistance: To avoid the affects of any solvents to wire mesh and to ensure the safety of

print screen.

Products Specification
