Description
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: NOAH
- Model Number: SCB10
- Usage: Electronic
- Phase: Three
- Coil Structure: Toroidal
- Coil Number: Autotransformer
- Rated capacity: 30-10000kva
- Frequency: 50Hz/60Hz
- Voltage: 6.6-35kv
- Installation: Indoor/Outdoor
- Insulation level: Class H/F
- Coil material: Copper/Aluminum coil
- Core: Cold Rolled Grain Oriented Silicon Steel Sheet
- Cooling: AN/AF
- Protection Grade: IP00-IP20(Indoor)-IP23(Outdoor)-(Customizing)
- Highest Temperature: 100K
All kinds of Dry-type Transformers, especially applicable for Power plant, High-rise Building, Business Center, Vessel, Port, Station Airport, Petrochemical Plant Railway, Tunnel, Mine Underground, Urban Centralized Residential Quarter which is high demand for fireproofing, explosion proofing antipollution.
Less PD, long service life. As the coil is cased by vacuuming under the condition of “positive pressure”, so there is no air bubbles between turns and layers, greatly reducing the amount of partial discharge. In addition, the mechanical strength is supper great after epoxy casting, strong capability of resistance against sudden short-circuit. With impeccable temperature protection and housing guards, it guarantees the products to run safe and reliably.
High-voltage coil is like a “cake” structure, improving the coil electrical load strength and cooling capacity of product. Low voltage coil are wound with copper foil, reducing the problem of coil end leakage reactionary. In order to lower down the no-load losses, noise and improve the strength of core mechanical, we use WISCO 30Q120 silicon steel.
Product Parameter
|
Rated
|
No-load
|
Load
|
No-load
|
Short
|
Noise
|
Dimension
|
|
Gauge(mm)
|
Weight(kg)
|
|
Capacity (KVA)
|
power(W)
|
Loss(120C,W)
|
Current(%)
|
Circuit
|
Level dB(A)
|
|
|
|
|
|
|
|
|
|
Impedance(%)
|
|
Without
|
With
|
|
|
|
|
|
|
|
|
|
Cabinet
|
Cabinet
|
|
|
|
|
|
|
|
|
|
(L*W*H)
|
(L*W*H)
|
|
|
|
30
|
190
|
710
|
2.4
|
4
|
45
|
840*800*920
|
1150*1000*1200
|
500
|
360
|
|
50
|
270
|
1000
|
2.4
|
|
|
880*800*1000
|
1200*1000*1310
|
|
510
|
|
80
|
370
|
1380
|
1.8
|
|
|
940*800*1080
|
1300*1200*1410
|
|
660
|
|
100
|
400
|
1570
|
1.8
|
|
|
1030*800*1105
|
1400*1200*1450
|
550
|
710
|
|
125
|
470
|
1850
|
1.6
|
|
|
1040*800*1120
|
1400*1200*1450
|
|
830
|
|
160
|
540
|
2130
|
1.6
|
|
|
1130*800*1160
|
1400*1200*1450
|
|
980
|
|
200
|
620
|
2530
|
1.4
|
|
|
1140*800*1125
|
1500*1200*1500
|
|
1160
|
|
250
|
720
|
2760
|
1.4
|
|
|
1180*800*1245
|
1500*1200*1550
|
|
1280
|
|
315
|
880
|
3470
|
1.2
|
|
|
1200*800*1280
|
1550*1300*1650
|
660
|
1350
|
|
400
|
980
|
3990
|
1.2
|
|
|
1240*800*1430
|
1550*1400*1700
|
|
1580
|
|
500
|
1160
|
4880
|
1.2
|
|
|
1260*800*1505
|
1600*1400*1850
|
|
1790
|
|
630
|
1300
|
5960
|
1
|
6
|
50
|
1380*900*1400
|
1700*1400*1800
|
|
2130
|
|
800
|
1520
|
6960
|
1
|
|
|
1460*900*1525
|
1800*1400*2000
|
|
2460
|
|
1000
|
1770
|
8130
|
1
|
|
|
1580*960*1665
|
1950*1400*2000
|
820
|
2910
|
|
1250
|
2090
|
9690
|
1
|
|
|
1660*960*1750
|
2000*1400*2100
|
|
3630
|
|
1600
|
2450
|
11730
|
1
|
|
|
1760*1010*1980
|
2100*1500*2200
|
|
4340
|
|
2000
|
3050
|
14450
|
0.8
|
|
|
1900*1010*2050
|
2250*1500*2400
|
|
5050
|
|
2500
|
3600
|
17170
|
0.8
|
|
|
1980*1010*2010
|
2350*1500*2500
|
|
5870
|
Product Features
Fireproof, long service life.
Maintenance is simple, safe and reliable.
High mechanical strength of the whole cast coil capable of withstanding sudden short-circuit.
Strong capability of moisture-proof anti-corrosion.
